| PUMP SPECIFICATION | JP13-250 |
|---|---|
| Working Pressure | 30-250 bar / 435-3625 PSI |
| Flow rate | 8.5-17 LPM/ 2.25-4.49 GPM |
| Pump Type | CL5 |
| Inlet max temperature | 40o C |
| ENGINE SPECIFICATION | |
| Engine | Honda GX 390 |
| Horsepower | 13 hp |
| RPM | 1700 |
| Fuel | Petrol (Gasoline) |
| MACHINE DIMENSIONS (LXWXH) | 100 X 66 X 92 cm |
| Weight | 61 kg / 134 lbs |
Ultra high pressure hoses: 10 meter
Gun: Trigger operated dump gun stainless steel
Lance with nozzle
Bypass with safety valve
Suction and delivery S/S valves
Pressure regulator
Pressure gauge
Operator and spares manual
