| PUMP SPECIFICATIONS | |||
| Working Pressure | 500 bar / 7250 PSI | ||
| Flow Rate | 30 LPM / 7.92 GPM | ||
| ELECTRICAL SPECIFICATIONS | |||
| Power Motor | 30 kW / 40 HP | ||
| RPM (@50Hz) | 1450 | ||
| RPM (@60Hz) | 1750 | ||
| Power Supply | 3 Phase 380-440V 50Hz/60Hz | ||
| Machine Dimensions (LXWXH) | 1500 X 950 X 1000 mm | ||
| Weight | 500 Kg |
Electrical cable – 10 meter 4-core
Manual Pressure Regulating Valve
Note: Enables the adjustment of pressure from 150 bar up to 500 bar by hand
Electric feed pump
Stainless steel filter
Stainless steel SS316 Electric Box
Operator and spares Manual
Galvanised base and frame
Pneumatic wheels and brake system
Epoxy Paint System 2 component
Primer Interzinc 22/ Inorganic Zinc Rich Silicate
Intermediate coat – Intergard 400/Epoxy
Top coat Interthane 990 / Polyurethane
High pressure hose: 20m with female ends BSP ½
Gun: Trigger operated gun
Lance: 750mm length
Nozzle: Fan Jet nozzle
