| PUMP SPECIFICATION | JE30-2018 |
|---|---|
| Working Pressure | 30-200 bar / 435-2900 PSI |
| Flow rate | 9-18 LPM/ 4.78-9.56 GPM |
| Pump Type | MPW5 |
| Max. inlet temperature | 40o C |
| Max. outlet temperature | 140o C |
| MOTOR SPECIFICATION | |
| Electric Motor | 8.7 kW / 11.66 HP |
| RPM | 1700 @ 60 Hz |
| Power Supply | 3 phase 380-440 V 60Hz |
| MACHINE SPECIFICATION | |
| Diesel tank | 22 l / 5.8 gal |
| Detergent tank | 22 l / 5.8 gal |
| Anti-scale tank | 2.4 l / 0.6 gal |
| Fuel consumption | 6.6 l/h / 1.75 gal/h |
| Heat output | 88 kW |
| MACHINE DIMENSIONS (LXWXH) | 125 X 69 X 87 cm |
| Weight | 175 kg / 385 lbs |
Electric Cable: 5 meter with plug
Ultra high pressure Hoses: 10 meter
Gun: Trigger operated gun stainless steel
Lance with straight jet nozzle
Low voltage and delayed Total Stop
Temperature regulation gauge, with high sensitivity stainless steel sensor
Header tank and anti-scale device
Pressure accumulator for hose and gun vibrations preventions
