| PUMP SPECIFICATION | JE30-1310D |
|---|---|
| Working Pressure | 30-110 bar / 435-1595 PSI |
| Max. Pressure | 150 bar / 2175 GPM |
| Flow rate | 330-660 l/h / 1.52-2.91 GPM |
| Max. inlet temperature | 40o C |
| Max. outlet temperature | 90o C |
| MOTOR SPECIFICATION | |
| Electric Motor | 3 kW / 4 HP |
| RPM | 2800 @ 50 Hz |
| Power Supply | 1 phase 230V 50Hz |
| MACHINE SPECIFICATION | |
| Diesel tank | 14 l / 3.7 gal |
| Detergent tank | 2.5 l / 0.66 gal |
| Fuel consumption | 2.83 l/h / 0.75 gal/h |
| Heat output | 38 kW |
| MACHINE DIMENSIONS (LXWXH) | 80 X 55 X 83 cm |
| Weight | 55 kg / 121 lbs |
Three ceramic coated pistons, brass axial pump head with built-in bypass valve
Electric Cable – 5 meter
Ultra high pressure hose – 8 meter
Pressure regulator
Gun: Trigger operated
Lance with jet nozzle
Total Stop
Suction and delivery S/S valves
Vertical burner with high thermal efficiency steel coil
Temperature regulation gauge
Diesel pump with by-pass valve
Detergent built-in tank for indirect suction
Glycerin pressure gauge
Ergonomic handle
Power cable holder
Accessory holder
Operator and spares manual
