| PUMP SPECIFICATION | JE20-2015 |
|---|---|
| Working Pressure (bar) | 30-200 bar / 435-2900 PSI |
| Flow Rate | 9-15 LPM / 2.38-3.96 GPM |
| Pump Type | MPW5 |
| Inlet max temperature | 40o |
| MOTOR SPECIFICATION | |
| Electric Motor | 7.0 kW / 9.4 HP |
| RPM | 1450 @ 50 Hz |
| Power Supply | 3 phase 380-400V 50Hz |
| MACHINE DIMENSIONS (LXWXH) | 50 X 90 X 83 cm |
| Weight |
56 kg / 123 lbs
|
Electrical Motor: 4-pole with thermal protection and water-cooling
Full ceramic pistons, brass linear pump head with built-in bypass valve
Integrated elastic joint
Electric Cable – 5 meter
Ultra high pressure hose – 10 meter
Pressure regulator
Gun: Trigger operated dump gun stainless steel
Lance with straight jet nozzle
Low voltage and delayed Total Stop
Suction and delivery S/S valves
Integrated detergent suction w/ suction probe
Glycerin pressure gauge
Steel gauge and covers
Operator and spares manual
