| PUMP SPECIFICATION | JE20-1211 |
|---|---|
| Working Pressure (bar) | 30-125 |
| Working Pressure (PSI) | 435-1812 |
| Flow Rate | 5.75-11 lpm / 1.52-2.91 GPM |
| Pump Type | MPW5 |
| Max. inlet temperature | 40o |
| MOTOR SPECIFICATION | |
| Electric Motor | 3 kW / 4 HP |
| RPM | 1450 @ 50 Hz |
| Power Supply | 1 phase 230 V 50Hz |
| MACHINE DIMENSIONS (LXWXH) | 50 X 90 X 83 cm |
| Weight | 44 kg / 96.8 lbs |
Electrical Motor: 4-pole with thermal protection
Three ceramic pistons, brass linear pump head with built-in bypass valve
Electric Cable – 5 meter
Ultra high pressure hose – 10 meter
Pressure regulator
Gun: Trigger operated gun
Lance with jet nozzle
Total Stop
Suction and delivery S/S valves
Detergent built-in tank for indirect suction
Glycerin pressure gauge
Accessory holder
Power cable holder
Ergonomic handle
Operator and spares manual
