| PUMP SPECIFICATION | JE10-1510 |
|---|---|
| Working Pressure (bar) | 30-150 (max. 160) |
| Working Pressure (PSI) | 435-2175 (max. 2320) |
| Flow Rate | 5.75-9 lpm / 1.52-2.38 GPM |
| Pump Type | MP3 |
| Max. inlet temperature | 40o |
| MOTOR SPECIFICATION | |
| Electric Motor | 3 kW / 4 HP |
| RPM | 1450 @ 50 Hz |
| Power Supply |
1 phase 230V 50Hz
|
| Detergent Tank | 3.8 l / 1 gal |
| MACHINE DIMENSIONS (LXWXH) | 76 X 41 X 75 cm |
| Weight | 33 kg / 72.75 lbs |
Our Features
- Electrical Motor: 4-pole with thermal protection
- Three ceramic coated pistons, brass linear pump head with built-in bypass valve
- Electric Cable – 5 meter
- Ultra high pressure hose – 8 meter
- Pressure regulator
- Gun: Trigger operated
- Lance with jet nozzle
- Total Stop
- Suction and delivery S/S valves
- Detergent built-in tank for indirect suction
- Glycerin pressure gauge
- Accessory holder
- Power cable holder
- Ergonomic handle
- Operator and spares manual
