| PUMP SPECIFICATIONS | |
| Working Pressure | 500 bar / 7250 PSI |
| Flow Rate | 29 LPM / 7.66 GPM |
| ENGINE SPECIFICATIONS | |
| Type | Kubota Industrial 4 Cylinder |
| Power hp | 28/21 |
| Power kW | 54.9kW & 2600 Rpm |
| Machine Dimensions (LXWXH) | 1550 x 1100 x 1250 mm |
| Approx. Weight | 800 Kg |
Manual Pressure Regulating Valve (Free of Charge)
Note: Enables the adjustment of pressure from 150 bar up to 500 bar by hand
High pressure hose: 20m with female ends BSP ½
Gun: Trigger operated gun
Lance: 800mm length
Nozzle: Fan Jet nozzle
Thermo-mechanical valve to protect the valve from high temperature
Flexible coupling between Pump and Motor, for maximum component protection
Control Panel, with Start/Stop switch, and Indicators for monitoring engine parameters (engine oil, temperature, battery, etc.)
Feed Pump 1.8 bar
Operator and spares Manual
Galvanised stationary frame, with forklift pockets and lifting points
Water Tank 50 ltr
Epoxy Paint System 2 component
Primer Interzinc 22/ Inorganic Zinc Rich Silicate
Intermediate coat – Intergard 400/Epoxy
Top coat Interthane 990 / Polyurethane
High pressure hose: 20m with female ends BSP ½
Gun: Trigger operated gun
Lance: 800mm length
Nozzle: Fan Jet nozzle
